主要用途
廣泛應用于中藥材的洗凈、軟化、蒸制處理，如洗藥后可繼續進行負壓浸潤、加壓浸潤、熱潤或蒸制的選項加工。

Main uses
Widely used in areas of herb washing, softening and moistening, and could soften, moisten and steaming the herb under pressure.

主要特點
本機采用PLC+觸授屏控制，數控化生產，可設定及存貯溫度、轉速、時間、壓力、液位等工藝參數。本機采用先進工藝.可減少藥物有效成分流失，縮短周轉時間，提高生產效率，一機多用，節能減排，本機開關門安全炅活，電氣控制系統及管路氣動元件操作方便，設定簡單，顯示直觀，控制穩定性高.符合GMP要求。

Main technical characteristics
Digitally operate able. PLC+ operable screen, the parameters of the temperature, time, pressure and liquid level could be set easily. With advanced technologies, the processing cycle is shortened and the efficiency is improved. The machine is easy to operate and maintain , could meet the requirements of GMP.

型號 Type	主機 設計壓力 MPa	主機 設計溫度 ℃	主機 內室尺寸 mm	主機 容積 m³	旋轉 筒體尺寸 mm	旋轉 筒體容積 m³	旋轉筒體 裝料系數	旋轉 筒體轉數 r/m	儲液罐 尺寸 mm	儲液罐 容積 m³	總功率 m³
RWYX3600	0.35	147	φ1200x3000 厚6	3.6	φ900x3000	1.9	0.6	5~15	φ800x1500 厚度5	0.9	12
