主要用途
適用于醫藥、化工、食品、冶金、建筑等行業。對堅硬、難粉碎的物料進行加工，包括對塑料、樹根進行粉碎.也能作為微粉碎加工前道工序的配套設備。
Main uses
The machine can be used in the industries of medicine, chemistry, food, metallurgy and construction, to smash hard materials, including plastic, roots. And it also can be used to smash herb before the herb is powdered.
主要特點
獨特的動、定刀剪切結構，動、定刀均可獨立調整，篩網拆裝方便，易維修，符合GMP要求。
Main technical characteristics
The machine is the horizontal structured, so ii is not affected by the hardness or glutinosily of the herb. And good smashing result can be achieved. The screen can be removed and repaired easily, thus it can meet the GMP requirements.
型號
Type |
生產能力
Capacity
(kg/h) |
粉碎室尺寸
Smashing chamber
dimension (mm) |
主軸速度
main axis speed
(r/m) |
電機功率
motor
(KW) |
外形尺寸
dimension
(mm) |
總重量
weight
(kg) |
|
SC-400 |
100-500 |
195x400 |
500 |
5.5 |
720x820x1390 |
450 |
|
SC-600 |
200-750 |
335x600 |
450 |
15 |
1500x1200x1700 |
900 |
